Upgrade your power experience with our state-of-the-art 24V22 lithium battery, engineered to deliver unparalleled performance and reliability. Equipped with advanced communication capabilities, this battery offers seamless integration with your devices, providing real-time monitoring and control for optimal efficiency.
Brand:
SuperpackProduct Origin:
ChinaColor:
BlackLead Time:
25-30 Working Days"Power Up Your Medical Cart: Reliable Battery Solutions for Seamless Mobility! Are you seeking uninterrupted performance for your medical cart? Look no further! Our cutting-edge medical cart batteries ensure seamless mobility and dependable power, keeping your equipment operational when it counts. Say goodbye to downtime and hello to efficiency with our innovative battery solutions. Trusted by healthcare professionals worldwide, our batteries deliver reliable performance, even in the most demanding environments. Backed by rigorous testing and industry-leading safety standards, our batteries provide peace of mind, allowing you to focus on delivering superior patient care. Experience the difference with our state-of-the-art batteries. Contact us today to learn more!"
Main Features
• 25.6V 22Ah high performance LiFePO4 battery.
• LiFePO4 is the safest mainstream Li-ion battery.
• Ultra-long lifespan, up to 10X longer cycle life than lead acid equivalent.
• Light weight, 40% of the weight of comparable lead acid battery.
• Smart BMS with accurate SOC/SOH estimates, cycle life records and SMbus communication.
• Constant power available and stable voltage throughout discharge.
• Rugged impact resistant ABS case and cover flame retardant to UL94: V-0.
• LED battery state of charge indicator.
• Support hot-swapping.
• Ultra-long warranty period, up to 5 years available.
Specifications:
|
ELECTRICAL PERFORMANCE |
|
|
Nominal Voltage |
25.6V |
|
Nominal Capacity |
22Ah |
|
Stored Energy |
563Wh |
|
Reserve Capacity |
Reserve Capacity |
|
Internal Resistance |
≤50.0mΩ |
|
Self-discharge Rate |
<3%/month |
|
Long Term Storage |
Charge every 6 months or as soon as OCV ≤25.6V |
|
CHARGE PERFORMANCE |
|
|
Maximum Charge Current |
22A |
|
Recommended Charge Voltage |
29.2V |
|
Balancing Voltage |
<28.8V (3.6V/cell) |
|
BMS Charge Cut-off Voltage |
BMS Charge Cut-off Voltage |
|
DISCHARGE PERFORMANCE |
|
|
Maximum Continuous Current |
22A |
|
Peak Current |
32A (3S) |
|
BMS Discharge Cut-Off Current |
60 A ± 1 A (31mS) |
|
Recommended Low Voltage Disconnect |
22.0 V (2.75V/cell) |
|
BMS Discharge Cut-Off Voltage |
>20.0 V (2S) (2.5V/cell) |
|
Reconnect Voltage(by charging) |
22.4V (2.8V/cell) |
|
Short Circuit Protection |
250 - 500μS |
|
Mechanlcal PERFORMANCE |
|
|
Dimensions(L*W*H/HT) |
195mm*130mm*165/183mm |
|
Weight |
12.6 lbs (5.7Kg) |
|
Terminal Type |
T11(M6) |
|
Case Material |
PC+ABS (UL94-V0) |
|
PC+ABS (UL94-V0) |
RJ45 |
|
Communication Protocol |
SMbus |
|
TEMPERATURE PERFORMANCE |
|
|
Discharge Temperature |
-4 ~ 131 ºF (-20 ~ 55 ºC) |
|
Charge Temperature |
32 ~ 113 ºF (0 ~ 45 ºC) |
|
Storage Temperature |
23 ~ 95°F (-5 ~ 35°C) |
