Superpack SPF48V100 energy storage system is completed integrated with deep-cycle lithium iron phosphate battery. It is a low voltage energy storage system and a modular design battery pack 51.2V100Ah. It can be expanded energy from 5KWh to 75KWh for parallel connecting from 1pcs to 15pcs modules. The single module’s maximum output power 5KW. It is suitable for single/3 phase on/off hybrid inverter for residential energy storage system.
Brand:
SuperpackItem NO.:
SPF48V100Product Origin:
ChinaColor:
BlackLead Time:
25-30 Working DaysSuperpack 48V100Ah 5kwh battery is perfect for solar energy storage. This is a 48v On/Off-grid solar lithium battery unit and designed for rack mount installation.
Feature
●4U standard Rack-mounted design, easy to install and deploy, requires less space;
●More than 6000 times charge/discharge cycles life
●Application for off-grid solar power system
●Intelligent BMS equipped inside to maintain the battery always work at best condition
●Suitable for use in a wider range of applications where ambient temperature is unusually high: up to +60°C;
●Low resistance Ensure battery string consistency
●Application for off-grid solar power system
●Parallel use of batteries Meet large capacity requirements
●Communication: CAN, RS485, RS232
Product Specification
| Model | SPF48V100 |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 100Ah |
| Charging Cut-off Voltage | 57.6V |
| Charging method | Constant Current with limited Voltage- Constant Voltage with limited Current |
| Max. Continuous Charge Current@25℃ | 100A |
| Max. Continuous Discharge Current@25℃ | 100A |
| Max Discharge Power @25℃ | 5.12KW |
| Peak Discharge Power @25℃,100ms | 7.68KW |
| Discharge Cut-off Voltage | 43.2V |
| ChargeTemperature | 0℃ ~ 45℃ |
| Discharge Temperature | -20℃ ~ 60℃ |
| Weight | ≈53Kg |
| Dimension | (482*600*177)±2mm |
| Internal Resistance | 35mΩ |
| Communication Mode | RS232/RS485 |
