Customizable Systems: Configurable communication protocols and intelligent BMS for safety and performance.
High Discharge Rate: Handles instant peak currents, ideal for power-demanding applications.
Modular Design: Scalable parallel expansion for flexible voltage and capacity configurations.
Real-Time Monitoring: App support for live data tracking, including charge, voltage, and system health.
Compact & Lightweight: Smaller, lighter, and easy to handle without compromising power.
Wide Temperature Range: Reliable performance in diverse and extreme environmental conditions.
Brand:
SuperpackItem NO.:
SP-ESS-6kWh-B1Product Origin:
ChinaColor:
whiteLead Time:
25-30 Working Days
Features:
● High quality single cells.
● Intelligent BMS management system.
● 6kWh high capacity lithium iron phosphate cell.
● 3kW bidirectional inverter output.
● Supports UPS (uninterruptible power supply) settings.
● Intelligent Off Network Control System.
● With USB charging ports.
● Support 120V, 3kW photovoltaic power generation.
Application
Specifications
| Item | SP-ESS-6kWh-B1 |
| Electrical Characteristics | |
| Cell Chemistry | LiFePO4 |
| Nominal Voltage | 25.6V |
| Battery Energy | 6kWh |
| Cycle Life | >3000 Cycle @80%DOD,at 25°C |
| Communication | RS485/RS232/CAN |
| Standard Charge | |
| Charge Voltage | 29.2V |
| Standard Charge Current | 100A |
| Rapid Charge Current | 150A |
| Max. Charge Current | 150A |
| Standard Discharge | |
| Discharge Cut-off Voltage | 20A |
| Standard Discharge Current | 100A |
| Max. Continuous Discharge Current | 150A |
| Inverter | |
| Inverter | 170-280VAC; 50/60Hz |
| AC Output | 230VAC 50/60Hz |
| Rated Power | 3000W |
| MPPT | |
| MAX.PV Array Power | 3000W |
| MPPT Operating Voltage | 90-450VDC |
| MPPT Max Charge Current | 80A |
| UB-A | |
| Specification | 5V 3.6A |
| Temperature | |
| Charge Temperature | 0°C~55°C |
| Discharge Temperature | -20°C~65°C |
| Mechanical | |
| Dimensions (H*W*D) | 610*560*270mm |
| Weight | 86.5±0.5Kg |
